Inverted Olympus IX80

FL3 Training Guide Location: Rm 6.033 Bookings

Olympus IX80 Inverted Microscope Stand with Nikon DS-FI3 sCMOS camera

Inverted widefield microscope with Halogen lightsource and sCMOS camera. Suited for imaging fixed fluorescent samples.

Features Include:

Manual X-Y-Z stage
Brightfield & DIC
Fluorescence
Colour Camera

Transmitted Light: Olympus 100W Halogen Lamp

Reflected Light: XCite 120Q Halogen White Lightsource

Condensor:

Name	N.A.	W.D. mm	Position 1	Position 2	Position 3	Position 4	Position 5	Position 6
Universal LWD	0.45	54	Open	PhL	Ph1	Ph2	DIC I	DIC II

Objectives:

Position	Objective	Magnification	N.A.	Immersion	W.D. (mm)	Type	Type	Thread
1	U Plan Fluorite	4x	0.13	Dry	17			M23
2	U Plan Apochromat	10x	0.4	Dry	3.1			M23
3	U Plan S Apochromat	20x	0.75	Dry	0.65			M23
4	U Plan FLN	40x	0.75	Dry	0.51			M23
5	U Plan S Apochromat	63x	1.35	Oil	0.17			M23
6	U Plan Apochromat	100x	1.35	Oil	0.10	DIC III		M23

Fluorescent Filter Sets:

Position	Name	Excitation	Dichroic	Emission	Suitable Dyes
1	DAPI - 5060C	377/50	409LP	447/60	DAPI, Hoechst
2	CFP - 2432C	438/24	458LP	483/32	CFP, Cerulean
3	GFP-3000B	488/10	505LP	530/60	GFP, A488
4	YFP-2427B	500/24	520	542/27	YFP
5	mCherry-40LP	560/20	580LP	585LP	mCherry, Cy3
6	-	-	-	-	-

Computer:

Dell PC - 2.0GHz i5 Processor - 16GB RAM

1TB Raid Array

47" TV Monitor

Software:

Windows 10 Enterprise LTSC

NIS Elements F
